Kirisun TM840 Service Manual

TM840 Service Manual
Control panel PCBA BOM
1 6SS2-4073-HFB STM-U Mobile panel jacking
270 3CL3-PH-20002 R Bar connector 1
271 3SE3-RE1100MD1-H01 encoding switch socket 1
272 7MBP-4028-01A-C KME221 Aviation plug（male head） 1
273 4PE3-3R0-Y25 luminous diode 1
274 6SS1-4073-HFC STM-U Mobile panel Chip jacking 1
275 2CC1-10-X5R100-104K R Chip Multilayer Capacitor 1 C829
276 2CC1-16-Y5V500-104Z Chip Multilayer Capacitor 11 C25，C1，C3，C2，C15，C20，C26，C17，C18，19，C22
277 2CC1-16-C0G500-101J R Chip Multilayer Capacitor 11 C6，C23，C24，C27，C28，C29，C30，C31，C32，C33，C34
278 2CC1-10-C0G500-101J R Chip Multilayer Capacitor 13 C35，C36，C37，C38，C39，C40，C41，C42，C43，C44，C45，C46，C47
279 2CC1-16-X5R6R3-475K Chip Multilayer Capacitor 4 C14，C16，C21，C830
280 3CF1-40FMN-BMT-A-TF R Chip FFC/FPC Connector 1 J1
281 3CC1-1226-20-03-H12 LCD interface socket 1 J3
282 1DS1-HVC131 R Chip switching diode 2 D2，D3
283
5FE1-BLM15AG221SN1
D
EMI suppression filter 22
FB2，FB3，FB4，FB9，FB10，FB12，FB13，FB14，FB15，FB16，FB17，
FB18，FB19，FB20，FB21，FB22，FB23，FB24，FB25，FB26，FB27，FB28
284 5FE1-BLM18PG181SN1 Chip EMI suppression filter 3 FB1，FB5，FB11
285 5FE1-BLM21PG221SN1 Chip EMI suppression filter 2 FB7，FB8
286 3FW1-42932-302320 R Chip fuse 1 F1
287 4PE1-16-F9 Chip luminous diode 6 LED1，LED2，LED3，LED4，LED5，LED6
288 1TT1-DTC114YE Chip triode 5 Q1，Q5，Q6，Q7，Q908
289 1DZ1-PESD24V0S1UB Chip Zener diode 3 D7，D8，D9
290 1DZ1-PESD3V3S1UB Chip Zener diode 6 D1，D5，D12，D15，D16，D59
291 1DZ1-PESD5V0S1UB
Chip Zener diode DP770，DP780，STP
，
KH620
5 D6，D10，D11，D13，D14
292 1TF1-ST2301 R Chip MOSFET 2 Q3，Q4
293 2RS1-16-102J R Chip Resistance 2 R25，R28
294 2RS1-16-104J R Chip Resistance 3 R10，R34，R29
295 2RS1-10-103J R Chip Resistance 1 R4
296 2RS1-16-100J R Chip Resistance 1 R26
297 2RS1-16-000O R Chip Resistance 4 R30，R31，R7，R8，
298 2RS1-16-103J R Chip Resistance 14 R3，R5，R6，R12，R13，R14，R1，R2，R9，R11，R18，R35，R36，R37
299 2RS1-16-330J R Chip Resistance 2 R15，R16
300 3ST1-IT-1102SMD Chip touch switch STP STP，KH620D 1 SW2
301 1IM1-TCA8418 I2C control keypad scan IC 1 U1
302 6PM7-4073-HFD STM-U Mobile panel PCB 1
46
