Kistler 9323AAA - Press Force Sensor Typ 93 X3 Au0109

Technical data
9323A_002-476e-11.24 Page 53
9.1.1 Press Force Sensor Type 93x3AU0109
Technical Data
Press Force Sensors
Type
9383AU0 109
9393AU0109
Compression force:
Measuring range Fz, max kN –50…500 a) –100 ... 950 b)
Overload Fz, max.
kN
–55/550
–110/1045
Calibrated range Fz
kN
customized
customized
Linearity incl. Hysteresis
%FSO
≤±1
≤±1
a) Minimal pretension: F
v1
= 100 kN at max. compression force of Fz = 500 kN
b) Minimal pretension: F
v1
= 200 kN at max. compression force of Fz = 950 kN
