KitchenAid KDTM404EBS - TESTING

TESTING
KitchenAid 2015 Microltration Dishwashers
n
6-1
Section 6:
Testing
This secon provides a wiring diagram, control board
specicaons, tesng procedures and strip circuits the
“KitchenAid 2015 Microltraon Dishwashers.”
n Tesng Safety
n Wiring Diagram
n Control Board Informaon
n General Theory of Operaon
n Power Check
n Door Switch Circuit
n Fill Circuit
n Dispenser Circuit
n Water Heang/Heat Dry
n Water Sensing w/OWI
n Diverter Motor
n Diverter Sensor/Posion Switch
n Wash Motor
n Drain Motor
n Lower Spray Arm Motor
n AC Fan Motor
n Interior LED Lighng
n User Interface (UI)
n Notes
