KitchenAid KDTM404EBS - COMPONENT ACCESS

COMPONENT ACCESS
KitchenAid 2015 Microltration Dishwashers
n
4-1
Section 4:
Component Access
This secon provides service parts access, removal,
and installaon instrucons for the “KitchenAid 2015
Microltraon Dishwashers.”
n Insulaon Blanket
n Door Latch Strike
n Door Spring Adjustment
n Water Inlet & Drain Hose
n Advanced ProDry™ (Side Dry)
n Overll Assembly
n Interior LED Lighng
n Accessing Door Components
n Removing User Interface
n Removing Latch Assembly
n Removing Dispenser Assembly
n In Tub Components
n Spray Arms, Feed Tube, and Manifold
n Removing the Racks
n Removing the Lower Spray Arm
n Removing ProScrub® Manifold & Feed Tube
n Removing Diverter Disk
n Under Tub Components
n Removing Electronic Control
n Removing Heater Assembly
n Removing Drain Pump & Sump Assembly
n Removing Opcal Water Indicator
n Removing Diverter Assembly
n Microltraon Wash System Parts
n Removing Wash Motor & Rotang Inlet Filter
Video Available Look for this ICON throughout Secon 4
Multimedia
Enhanced
