GENERAL INFORMATION
KitchenAid 2015 Microltration Dishwashers
n
1-3
General Theory of Operation
2015 KitchenAid Microfiltration Wash System
No Filter Cup, No Chopper
The industry’s rst microltraon system is a clear departure
from tradional, passive ltraon because it connuously
lters 100% of the water, reducing the cycle me and energy
consumpon on the heaviest loads.
Similar on the Surface, Radically Different Inside
The only visible ltraon component of the new ltraon
system is the coarse lter in the boom of the tub. The rest of
the high-performance ltraon system is below the tub.
How Microfiltration Works (See Figure 1)
1. Water and food parcles ow through the coarse lter (A)
into the lter housing.
2. An impeller pulls wash and rinse water into the spinning
ultra-ne lter (B).
3. The ultra-ne lter is cleaned by an area of back-pressure
(C) created by two sets of wing-shaped blades located
inside (D) and outside (E) the lter.
4. Food parcles remain suspended inside the lter housing;
ltered water is pumped back to the wash arms.
5. During draining, a secondary pump ushes out food
parcles and soils.
A - Coarse Filter
B - Spinning Ultra Fine Filter
B
C
D
E
Figure 1 - Microfiltration Wash System
C
Area of Back Pressure
Wash Flow
Drain Flow
Wash
Motor
Dirty
Water
Enters
Drain
Motor
Food Soils
Flushed Out
Impeller

KitchenAid KDTM404EBS Specifications

General

Style	built-in dishwashers
Color	black stainless steel
Load Capacity	16
Number of Cycles	6
Cycle Selections	express wash, light/china, normal, prowash, rinse only, tough
Options/Settings	1-24 hour delay, control lock, heated dry, hi temp wash, prodry, proscrub upper, proscrub, sani rinse, top rack wash
Drying Type	heated drying
Noise level	44 decibels adjusted
Control Type	touchpad
Delay Start	yes
Child Lock	yes
Number of Racks	3
Water Filter	yes
Water Softener	no
Food Disposer	no
Sanitize Settings	yes
Smart Home	no
Annual Energy Consumption	270 kilowatt hours
Voltage	120 volts
Current	15 amperes

Weight and Dimensions

Depth	24 3/4 inches
Height	34 1/2 inches
Width	23 7/8 inches
