KitchenAid 2015 Microltration Dishwashers
GENERAL INFORMATION
Dishwasher Specifications
Line Voltage/Frequency : 120 VAC/60 Hz
Amps : 10A
Low Volts Power Supply : -5 VDC (REF), 13 VDC (+8V, -5V), Neutral (VCC)
Supply Water Flow Rate : To ll 2 qt (1.9 L) in 27 seconds, 120 psi maximum, 20 psi minimum
Supply Water Temperature : Minimum - 120° F (49° C)
Water Charge : 1.0 gal. (3.9 L) Approximate
Control : Electronic Control
Wash Motor : 120 VAC, Run Winding (3-7 W), Aux Winding (6-10 W)
Drain Motor : 120 VAC (15-25 W)
Fill Valve : 120 VAC, (890-1,090 W)
Heater : 120 VAC, (8-30 W)
Dispenser : Solenoid: 120 VAC, (260-300 W)
Wax Motor: 120 VAC, (1.4K-2.8K W)
Diverter Valve Motor : 120 VAC, (1300-1600 W)
Spray Arm Motor : 120 VAC, (1,890-2,310 W each coil) (some models)
Vent Wax Motor : 120 VAC, (600-1,800 W)
Fan Motor : 5 VDC, (31K-41K W)
Interior Lighng : LEDs (13 VDC) (some models)
Sensors : NTC Thermistor
Water Sensor (OWI)
Spray Arm Sensor (some models)
Switches : Diverter Posion Switch (5 VDC)
Door Switch (13 VDC)
Float Switch (120 VAC)
TCO / Bi-Metal : Incorporated into Control Board (Penninsula Slots)
Fuse : F9 = Small Triac Load Fuse
Wash System : Clean Water Wash System (RIF)
Lower Spray Arm Rotaon : 12 to 40 rpm
Upper Spray Arm Rotaon : 12 to 30 rpm
Filtraon : Rotang Inlet Filter (Microltraon)
Advanced ProDry™ : Available on all models
ProScrub™ : Available on all models
Dynamic Wash Arm : Available on certain models
Window with Lighted Interior : Available on certain models
Bole Wash : Available on certain models
Depth : 24 3/4” (62.86 cm) without handles, 27 1/2” (69.85 cm) with handles
Height : 34 1/2” (87.63 cm) max., 33 1/2 (85.09 cm) min.
Width : 23 7/8” (60.64 cm)
Weight : 102 lbs. (46.27 kg)

KitchenAid KDTM404EBS Specifications

General

Style	built-in dishwashers
Color	black stainless steel
Load Capacity	16
Number of Cycles	6
Cycle Selections	express wash, light/china, normal, prowash, rinse only, tough
Options/Settings	1-24 hour delay, control lock, heated dry, hi temp wash, prodry, proscrub upper, proscrub, sani rinse, top rack wash
Drying Type	heated drying
Noise level	44 decibels adjusted
Control Type	touchpad
Delay Start	yes
Child Lock	yes
Number of Racks	3
Water Filter	yes
Water Softener	no
Food Disposer	no
Sanitize Settings	yes
Smart Home	no
Annual Energy Consumption	270 kilowatt hours
Voltage	120 volts
Current	15 amperes

Weight and Dimensions

Depth	24 3/4 inches
Height	34 1/2 inches
Width	23 7/8 inches
