SOFT 80, SOFT 100 PELLET-BURNING STOVE
Sub-menu 02 – 03 – Weekly chrono
Allows for enabling, disabling and setting the weekly timer functions.
The weekly timer has four time slots delimited by the set times, as shown in the following diagram (they do not have to
be used simultaneously):
- Buttons 1 and 2 (Increase and Decrease) are used to modify the selected value.
- Button 4 (Set) is used to select the next value.
- Button 5 (Esc) is used to select the previous value.
- Button 3 (ON/OFF) is used to return to the previous menu.
After setting the switch-on/off times and the power and temperature set-points, it is necessary to select the days on
which to enable the reference time slot. Shown below is the window in which the days must be enabled:
- Button 1 (Increase) is used to enable the selected day.
- Button 2 (Decrease) is used to disable the selected day.
- Button 4 (Set) is used to select the next day.
- Button 5 (Esc) is used to select the previous day.
- Button 3 (ON/OFF) is used to return to the previous menu.
Number of the selected time slot
(4 slots available)
Enable field
(It must be enabled if at least one
time slot is active)
Switch-on time
(OFF signals to the clock to
ignore the command)
SET OUTPUT
(Working power in the selected
time slot)
SET ROOM
(Room temperature in the
selected time slot)
Switch-on time
(OFF signals to the clock to
ignore the command)
Enabled days visualisation
field:
1-Monday / 2-Tuesday /
3-Wednesday / 4-Thursday /
5-Friday / 6-Saturday /
7-Sunday
(The full dot indicates that the day
is enabled)
Day enable field:
1-Monday / 2-Tuesday /
3-Wednesday / 4-Thursday /
5-Friday / 6-Saturday /
7-Sunday
(The full dot indicates that the day
is enabled)
