KLS Martin Minicutter - Page 2

2 Revision 08
Quick Instructions for Use Minicutter
For the assignment of the position numbers, see section 4.2 Functions of the Control Elements, Connections and Displays, page 11.
After voltage check: Connection to mains
Switching on
Connect neutral electrode to socket (11)
Apply neutral electrode to the patient
Monopolar operation
Bipolar operation
Connect handle with finger
switch to socket (13)
Connect handle without finger
switch to socket (13)
Connect foot switch to socket (13)
Connect bipolar instrument
to socket (14)
Connect foot switch to
socket (15)
Select bipolar coag
current (button 9)
Adjust output
power
Select cutting
current
Adjust output
power
Activate cutting current via
finger switch
Activate coag current via
finger switch
Adjust output
power
Select coag
current
Select cutting
current
Adjust output
power
Activate cutting current via
foot switch
Adjust output
power
Select coag
current
Activate coag current via
foot switch
Activate bipolar coag current
Deactivate bipolar coag current
HF activation via handle
HF activation via foot switch
CUT
COAG
COAG
CUT
