Instructions for Use
Electrosurgical Unit Minicutter
34 Revision 08
9 Technical Data
Designation Data electrosurgical unit Minicutter
Mains connection 100–240 V; 50/60 Hz
Power consumption without HF output approx. 16 VA
at max. output power approx. 120 VA
Protection class I
IP classification IP2X
Classification acc. to German
Medical Devices Act
II b
Leakage currents NF/HF acc. to IEC 60601-2-2
Type BF; defibrillator-proof
Nominal frequency 460/920/1,230 kHz
Modulation frequency 58/77 kHz
Operating mode Intermittent INT 10 s / 30 s corr. to 25 % duty factor
Mains fuses
T 1.6 AH, 250 V
G 5 x 20 mm
Signal level
HF display: 55 dB(A)
Alarm: 65 dB(A)
Weight approx. 3.9 kg
Radio interference suppression
Limit values according to DIN EN 55011 and DIN EN 60601-2-2
Radio interference immunity according to IEC 801
Dimensions W × H × D 270 x 120 x 250 mm
Environmental conditions for
transport and storage
Ambient temperature
Relative humidity
Air pressure
-25
°C to +70
°C (270 °F to 273 °F)
10–100%
500–1,060 hPa
Environmental conditions for
operation
Ambient temperature
Relative humidity
Air pressure
+10
°C to +40
°C (270 °F to 273 °F)
30–75%
700–1,060 hPa
Compliant with 93/42/EEC
