KMC Controls CTE-5202 Application Guide

General Information (All Applications) 9 CTE-5202 Applications Guide, AN0912A Rev. D
Thermostat Replaced
CTE-5202
Sequence
Selected
Example
Replacement
Applications
KMC / Nailor /
Dynacon*
Anemostat* Carnes*
Metal
Industries*
Nailor*
Price
Industries*
ASC /
Titus*
CTE-5101 999-2662 01EC-2119
B3-3001-191
or B3-191
019814-001
10269601 /
10269606
#1
See page 33,
page 34, and
page 41
CTE-5102 13-33 10269607
#3 (if T4 is not
used)**
See page 33
CTE-5103 13-35 999-2663 01EC-2122
B3-3001-186
or B3-186
019810-001
10269608 /
10269603
#3 (if T3 and
T4 are not
used) **
See page 35,
page 37, page
38, page 39, and
page 42
CTE-5104 13-34 999-2664 01EC-2120 H1-981
019726-001
/ 019816-
001
10269604 /
10269609
#2
See page 35,
page 36, and
page 40
CTE-5105 019822-001 10269610
#1 (if the
setback feature
is acceptable
in place of two
independent
setpoints)
*NOTE: CTE-510x thermostats require a power supply of 14–20 VDC, typically using the 16 VDC power supplied by a CSP-5001/5002
controller/actuator. The CTE-5202 can use the same 16 VDC power (or 14–35 VDC or 24 VAC). See also the CSP-5001/5002
Applications Guide.
**For applications requiring limited T1 and/or T2 signals and unlimited T3 and/or T4 signals, flow limits may need to be set on the
controller (allowing the controller to use an unlimited signal). Limits for the CTE-5202 and AO1 and AO2 would then be left at the
default 0 and 12.
KMC CTE-50xx
Thermostat Replaced
CTE-5202 Sequence Selected Example Replacement Applications
CTE-5001/5011* #1
See page 45 and page 48 (9.1 VDC)
CTE-5002/5012* #2
See page 47 (9.1 VDC)
CTE-5003/5013* (No Replacement) (9.1 VDC)
CTE-5006/5016** #2
See page 35 (16 VDC)
CTE-5015** #1
See page 33 (16 VDC)
*NOTE: These models require a power supply of 9.1 VDC, typically supplied by a CEP/CSP-4xxx controller/actuator, and they have a
0–6 VDC output range. See the discussion on 9.1 VDC power under the CTE-1x0x cross-reference NOTE on page 8. Need for the REE-
1014 in applications is eliminated.
**NOTE: These models require a power supply of 14–20 VDC, typically using the 16 VDC power supplied by a CSP-5001/5002
controller/actuator. The CTE-5202 can use the same 16 VDC power (or 14–35 VDC or 24 VAC).
Other thermostats that the CTE-5202 can be a
functional/upgrade replacement for include:
• Honeywell TB7980 (check application and
specications)
• Johnson Controls (various—check application
and specications)
• Kele RTC-2P (with one or less remote inputs—
check application and specications)
• PEKO (various—check application and specica-
tions)
• Siemens (various—check application and speci-
cations)
• Viconics (various—check application and speci-
cations)
NOTE: Products and name brands mentioned
may be trademarks of their respective
companies.
