Menu Display
Loading a parameter set from
SmartMedia card
Loading a parameter set from
SmartMedia card
• Open parameter setting
• System control
• Open “Parameter sets” (Fig)
2 complete parameter sets (A, B) are
stored in the analyzer.
5 parameter sets can be stored on the
SmartMedia card. One of those can
be saved as parameter set A to the
analyzer:
• Select parameter set to be loaded
The activated parameter set is
displayed in measuring mode.
Note: Remote switching between
A and B is possible via the OK2 input.
Set 1
Set A
Set 2 Set 3
SmartMedia card
SW 3400-102: Loadable Parameter Sets
Parameter setting/System control/Parameter sets
Parameter sets (Administrator)
Abort
OK
For switchover see
"Function control matrix"
Parameter sets
Save parameter set
25.1°C
0.003mS/cm
Load parameter set
A,B (internal)
1,2 (card)
1,2,3 (card)
1,2,3.4 (card)
1,2,3,4,5 (card)
Parameter sets (Administrator)
Return
For switchover see
“Function control matrix”
Parameter sets
Save parameter set
25.0°C
0.003mS/cm
1,2,3.4 (card)
Load parameter set
Load parameter set (Administrator)
Abort
NOTE: Old parameter set
will be overwritten!
24.9°C
0.003mS/cm
Load from
3 (card)
2 (card)
B (internal)
4 (card)
5 (card)
1 (card)
mS/cm
°C
Time 11:49
Favorites menu
Set B
(internal
only)
