9
b. WIRE KOALA
Connect KOALA only using official cables and accessories, which are tested and meet the required
specifications. The use of cables or accessories not certified by the manufacturer will void the warranty
and may cause irreparable damage to KOALA.
example of connecting KOALA
1. Use the supplied AC adapter.
2. Based on your configuration, connect the external encoders provided in the kit or the VIRTUAL cable
for your lens in LENS port.
3. Connect the SYNC if necessary, otherwise, set the data rate according to your requirements in SETUP
WEB PAGE.
4. If using KOALA in CRANE mode, connect the corresponding accessory with the provided cable in
OPTION port.
5. Connect an Ethernet cable from KOALA to your 3D engine and configure the network.
c. AUTOLEVEL
Level TRIPOD, HEAD and CRANE (Crane mode) and proceed to the "AUTOLEVEL" function from the SETUP
MENU, in this way KOALA will be perfectly leveled with the camera.
HEAD CRANE / TELESCOPIC / SLIDER
NOTE: repeat this operation only if KOALA and/or OPTION is reassembled or moved.
