KOBE CH9130SQB - Page 22

20
(Optional Duct Cover)
ORIGINAL KIT
NO.
DESCRIPTION
MODEL /SIZE
PART NO.
01
Duct Cover-Mounting Bracket
C1-0203-0002
02
Screw (TS 4 x 8 mm)
C1-0708-0006
03
Duct Cover
RA1020DC
12-02000-430-51
04
Hood-Mounting Bracket
C1-0221-0330
05
Screw (3/16” x 3/8”)
C1-0707-0001
06
Rubber Stand
C1-0511-0201
07
Screw (TS 4 x 8 mm)
C1-0708-0006
RECIRCULATING KIT
NO.
DESCRIPTION
MODEL /SIZE
PART NO.
01
Duct Cover-Mounting Bracket
C1-0203-0002
02
A
B
T-Head Box
Box
C1-0241-1930-FA
Box Bracket
C1-0241-1930-FB
03
Screw (TS 4 x 8 mm)
C1-0708-0006
04
Recirculating Duct Cover
RA1020RD
12-02000-430-51F
05
6” Round Plastic Exhaust
C1-0505-0001
06
Aluminum Pipe
C1-0601-0004
07
Charcoal Filter
C1-0603-0302
08
Screw (3/16” x 1”)
C1-0707-0003
09
Hood-Mounting Bracket
C1-0203-0330
10
Screw (3/16” x 3/8”)
C1-0707-0001
11
Rubber Stand
C1-0511-0201
12
Screw (TS 4 x 8 mm)
C1-0708-0006
