KOBE CH9130SQB - Components of Package

5
COMPONENTS OF PACKAGE
(Must keep all material for returns or refunds)
Range Hood Box
Duct Cover Box – Model No. RA1020DC
(Sold Separately)
{A} KOBE Range Hood - 1
{B} Warranty Registration Card - 1
{C} Instructions Manual - 1
{D} Baffle Filter - 2 (for 30”, 36”, 42” hood)
- 3 (for 48” hood)
(E}Bottom Casing - 1 (for 30” hood)
- 3 (for 36” & 42” hood)
- 2 (for 48” hood)
{F} 7” Round Adapter – 1
{G} Oil Tunnel – 1
{A}
{B} {C}
{D} {E}
{F} {G}
{H} KOBE Adjustable Duct Cover - 1
{I} Screws Package – 1
{J} Duct Cover-Mounting Bracket – 1
{K} Hood-Mounting Bracket – 1
{H}
{I} {J}
{K}
- FOR MORE INFORMATION, PLEASE VISIT OUR WEBSITE www.KOBERangeHoods.com OR
CONTACT KOBE RANGE HOODS AT (626) 775-8880.
