KOBE CH9130SQB - Parts List

19
PARTS LIST
MODEL NO.:
CH9130SQB
CH9136SQB
CH9142SQB
CH9148SQB
NO.
DESCRIPTION
MODEL /SIZE
PART NO.
1
7” Round Adapter
C1-0505-0004
2
6” Round Plastic Exhaust
C1-0505-0001
3
Plastic Plate
C1-0507-0201
4
Hood Casing
CH9130SQB
10-1930A
CH9136SQB
10-1936A
CH9142SQB
10-1942A
CH9148SQB
10-1948A
5
Halogen Light Unit (12V 20W Max.)
C1-0403-0101
6
Control Unit
C1-0501-0101
7
Control Board
C1-0404-0401-A
8
Transformer Support
C1-0201-1930
9
Transformer (Motor)
C1-0402-A120-01
10
A
B
Air Chamber
Air Chamber (Top)
CH9130SQB
C1-0101-0880
CH9136SQB
C1-0101-0880
CH9142SQB
C1-0101-1542
CH9148SQB
C1-0101-1542
Air Chamber (Side)
CH9130SQB
C1-0102-1930
CH9136SQB
C1-0102-1930
CH9142SQB
C1-0102-1942
CH9148SQB
C1-0102-1942
11
Transformer (Light)
CH9130SQB
C1-0402-0120-40
CH9136SQB
CH9142SQB
C1-0402-0120-60
CH9148SQB
12
Capacitor
C1-0401-0120-01A
13
Processor Board Box
C1-0501-0102
14
Processor Board
C1-0404-0401-B
15
Screw (1/8” x 3/8”)
C1-0708-0003
16
Screw (TS 1/4 x 7/16)
C1-0703-0001
17
Motor (Right)
C1-0301-0120-17A
18
Motor (Left)
C1-0301-0120-18A
19
Turbine Impeller (Right)
C1-0251-0880-01
20
Turbine Impeller (Left)
C1-0251-0880-02
21
Oil Tunnel Seal
C1-0502-0301
22
Oil Tunnel
C1-0502-0203
23
Impeller Plastic Cover
C1-0251-0001
24
Safety Screen
C1-0602-0103
25
Safety Screen Screw
C1-0705-0001
26
A
B
Bottom Casing
4” Wide
CH9130SQB
B101-1930-09
3” Wide
CH9136SQB
B101-1936-09
5-1/4” Wide
CH9142SQB
B101-1942-09
4-1/2” Wide
CH9148SQB
B101-1948-09
4” Wide
CH9136SQB
B101-1930-09
27
Baffle Filter
B101-1930-15
