For wheel trims supplied ex-factory or from ŠKODA Original Accessories, the
anti-theft wheel bolt should be installed in the position marked on the back of
the wheel trim» page 88.
Notice
The attachment and the anti-theft wheel bolts are provided with a code num-
ber. A replacement attachment can be ordered from ŠKODA Genuine Acces-
sories using this.
Loosening/tightening wheel bolts
Fig. 90
Loosening the wheel bolts
›
Insert the wheel wrench onto the wheel bolt to the stop. Use the associated
attachment for the anti-theft wheel bolts » fig. 89 on page 88.
›
To loosen the screws, grasp the key end and rotate the screw about one
turn in the direction of the arrow » fig. 90.
›
Totighten the screws, grasp the key end and turn the screw about against
the direction of the arrow » fig. 90, until it is tight.
WARNING
If it proves difficult to undo the bolts, carefully apply pressure to the end of
the wrench with your foot. Keep hold of the vehicle when doing so, and
make sure you keep your footing - There is a risk of injury.
Raising the vehicle
Fig. 91
Jacking points for the jack
Fig. 92
Attach lifting jack
Before the vehicle is raised, please take note of the safety instructions » .
To lift the vehicle, us the jack from the tool kit. Position the car jack at the jack-
ing point closest to the flat tyre.
The jacking points are located on the lower sill » fig. 91.
›
Insert the crank
6
into the mount on the car jack
5
» page 86.
›
Position the base plate of the jack with its full area resting on level ground
and ensure that the jack will fit in the jacking point when raised » fig. 92 - .
›
Use the crank to raise the jack until its pawl covers the jacking point» fig. 92-
.
›
Raise the vehicle until the wheel is a little off the floor.
89
Emergency equipment and self-help
