Setting Up the Printer
1-7
5. Remove the label/wrapper from the ribbon.
6. Push the right side of the take-up spool into the rear spool holder on the
right.
7. Place the left side of the take-up spool into the rear spool holder on the
left.
8. Rotate the take-up spool until it locks into place.
9. If there is any slack in the ribbon, remove it by turning the take-up spool.
IMPORTANT: Slack in the ribbon can cause a paper jam when making
prints.
Installing the Print Catcher
The print catcher collects finished prints as they exit the printer.
• Set the print catcher into the printer as shown.
Label/wrapper
Take-up spool
Print catcher
