Adjustments
SM5440-1 – 18NOV97 31
Warning
Dangerous Voltage
[4] Energize the projector.
[5] Set the projector to the LO-LAMP position.
[6] Install and hold the AUTO FOCUS TARGET
SLIDE TL-3002 until it is fully seated in the GATE
MECHANISM.
[7] Look through the PROJECTION LENS hole and
observe the focus light path on the AUTO-FOCUS
TARGET SLIDE TL-3002. Check that the light
path is correct. If not, do the adjustment
procedure for the FOCUS LIGHT PATH.
Warning
Dangerous Voltage
[8] Disconnect the main power.
[9] Heat the 2 POSTS on the PHOTOCELL
HOUSING to allow the POSTS to bend enough to
pull the PHOTOCELL CIRCUIT BOARD up and
off the PHOTOCELL HOUSING. Use a
SOLDERING IRON.
[10] Remove the 2 Wratten FILTERS and the
PHOTOCELL MASK.
To Next Page
