PREVENTIVE MAINTENANCE
10DEC05
PM4825-1
Page
21 of 30
Installing the New LIGHT SEAL PLUSH
1 Remove:
• 2 COVERS
• 4 SCREWS
• LEFT CASSETTE GUIDE
• RIGHT CASSETTE GUIDE
• 2 SCREWS
• CASSETTE LOAD CRADLE
H194_1062GC
H194_1062GCA
2 COVERS
4 SCREWS
LEFT CASSETTE GUIDE
RIGHT CASSETTE GUIDE
2 SCREWS
CASSETTE
LOAD CRADLE
