Specifications
2011-09-09 2G0733 5-3
Environmental Requirements
Temperature • Operating: 15–33 °C (59–91 °F)
• Storage: From –40 through 60 °C (From –40 through 140 °F)
Relative Humidity • Operating: 20–80 % RH, noncondensing
• Storage: 10–90 % RH, noncondensing
Altitude 30 m (100 ft) below sea level to 2438 m (8000 ft) above sea level
Surface Condition The surface must be a level (must be level within 1 °) table top or counter
capable of supporting the weight of the imager. For the imager to operate
with no image degradation, surface vibration levels cannot exceed the
following:
Environmental Effects
• Heat Dissipation: total heat dissipation for the imager is
883 BTU/hour
• Acoustical Noise:
– Less than or equal to 75 dB-A at 1 m during a sound burst of 1 sec
or less
– Less than or equal to 65 dB-A at 1 m during normal operation
– Less than or equal to 50 dB-A at 1 m during idle mode
Laser Specifications
• Wavelength : Minimum 800 nm, nominal 810 nm, maximum 820 nm
• Laser Beam Divergence: Maximum 32 degrees, minimum 6.8 degrees
• Laser Maximum Power: 120 mW
• Radiation class: Class 3B invisible laser radiation
• Type: Diode
G
2
/Hz
Freq. Range Direction
1 x 10
-7
1–50 Hz Vertical or horizontal
6 x 10
-5
50–200 Hz Vertical or horizontal
5 x 10
-6
200–650 Hz Vertical or horizontal
1 x 10
-6
650–1000 Hz Vertical or horizontal
