5-14 A-61651 December 2009
Replacing the separation
roller or separation roller
tires
1. Open the scanner cover.
2. Pull the separation roller cover forward and remove the separation roller.
NOTE: The separation roller cover is spring-loaded. Hold the separation
roller cover back until you remove the separation roller, then
gently lower the roller cover back in place.
If you want to replace the separation roller, do Steps 3 and 4. If you want to
replace the separation roller tires, go to Step 5.
3. Insert the new separation roller. Be sure to line up the slots on the
separation roller with the holders.
4. Release the separation roller cover back in place and close the scanner
cover.
