CVS-126 Chapter 2 How to use the menu
0093132702-08 2-15
Display the Operation guide/Stop the
display of Operation guide
When displaying the menu, it sets whether or
not the operation guide is displayed at the lower
part on the display.
When setting to “No display of operation guide”,
the echo sounder image can be easily seen at
the menu operation.
1 Press the [MENU] key.
2 Select the [System] [Operation guide].
(See [2.1 How to operate the menu])
3 Press the [ ] key.
4 To display the Operation guide, select [ON].
To stop the display of Operation guide,
select [OFF]. (Press the [
] key or [ ] key)
5 Press the [MENU] key to close the menu.
Display the detection area/Stop the
display of detection area
The range of the search that can be detected in
the angle of beam spread of the transducer
used can be displayed.
1 Press the [MENU] key.
2 Select the [Display2] [Detection area].
(See [2.1 How to operate the menu])
3 Press the [ ] key.
4 To display the Detection area, select [ON].
To stop the display of Detection area,
select [OFF]. (Press the [
] key or [ ] key)
5 Press the [MENU] key to close the menu.
6 Caution: The beam angle of transducer
is different depending on the
transducer.
Setting of Depth measurement
Select the method for depth measurement,
which is shown on the display.
1 Press the [MENU] key.
2 Select the [Display2] [Bottom detection].
(See [2.1 How to operate the menu])
3 Press the [ ] key.
4 Select the [Bottom detection]. (Press the
[
] key or [ ] key)
5 Press the [MENU] key to close the menu.
Change the display color
The display color can be changed.
1 Press the [MENU] key.
2 Select the [Display2] [Color table 1] or
[Color table 2]. (See [2.1 How to operate
the menu])
3 Press the [ ] key.
4 Select the [Color table]. (Press the [ ] key
or [
] key)
5 Press the [ ] key.
6 Select the color. (Press the [ ] key or [ ]
key)
7 Press the [MENU] key to close the menu.
Change the scale type
The interval of indications of scale can be
changed.
1 Press the [MENU] key.
2 Select the [Display2] [Scale type]. (See
[2.1 How to operate the menu])
3 Press the [ ] key.
4 Select the [Scale type]. (Press the [ ] key
or [
] key)
5 Press the [MENU] key to close the menu.
Change the bottom color
The dark red color of sea bottom can be
changed.
1 Press the [MENU] key.
2 Select the [Display2] [Color table 2]
[Bottom color]. (See [2.1 How to operate
the menu])
3 Press the [ ] key.
4 Select the [Bottom color]. (Press the [ ]
key or [
] key)
Black 0, , , 176, , , 255 Red
5 Press the [MENU] key to close the menu.
