CVS-126 Chapter 3 How to use the menu2
0093132702-08 3-1
Chapter 3 How to use the menu2
3.1 Display of Menu
After powering on, besides the menu displayed
first with the [MENU] key, there are the other
menus as follows, of which setting does not need
to be frequently changed.
[In out], [Correct], [Setting], [Maintain]
Display the menu
1 Press the [MENU] key.
2 Select the [Next].
3 Press [ ] key to display the system menu.
Return to the normal menu
1 Select the [Prev].
2 Press the [ ] key to display the normal
menu.
3.2 Setting of External Input /
Output
Set the setting related to the input/output.
Buzzer Setting
Set the buzzer sound to ON/OFF.
Temp Source
Switch the Sensor/NMEA.
Use the built-in water temp meter fot sensor.
For setting of [NMEA], use the input value from
outside connected with NMEA of power
connector.
Speed Source
Switch the Sensor/NMEA.
Use the built-in speed meter for sensor.
For setting of [NMEA], use the input value from
outside connected with NMEA of power
connector.
Baud Rate
Change the transmission speed of external
input/output.
Match the transmission speed with that of
external equipment connected. (Setting: 4800,
9600, 19200, 38400)
Correct
In out
Setting
Maintain
Buzzer setting
Temp source
Speed source
Baud rate
NMEA monitor
OFF
InsideSensor
InsideSensor
4800
OFF
NMEA output data
NMEA output data
Return
Correct
In out
Setting
Maintain
A
djust
D.range
Display1
Display2
A
larm1
A
larm2
NAV
System
Display1
D.range
Display2
A
larm1
A
larm2
NAV
System
In out
Correct
Setting
Maintain
Next
A
djust
Prev
Prev
