CVS-126 Chapter 5 Installation
0093132702-08 5-1
Chapter 5 Installation
5.1 Items of Caution on Installation
To realize the full performance of echo sounder, the installation of CVS-126 must be performed by an
engineer who is officially authorized by our company. The installation work includes the following
content.
(1) Unpacking the components
(2) Inspection of configuration unit, spare, accessories and material for installation
(3) Check of power voltage and capacity of current
(4) Decision of installing location
(5) Installation of CVS-126 Display unit and transducer
(6) Installation of accessories
(7) Plan and execution of cable laying and connection
(8) Adjustment after completion of installation
Unpacking the components
Unpack the components and confirm that all of the items match with the contents on the equipment
configuration list. If not matched, Contact the dealer you purchased or our sales company.
Inspection of components and accessories
Inspect the appearance of each components and accessories and check that no dents or damage
exist.
If any dents or damage exist and they are believed to be caused by accident during transportation,
contact the transportation and insurance company and consult our sales company or our dealer
nearest to you.
Decision of Installing Location
To realize the full performance of equipment, install the equipment, considering the points mentioned
below.
(1) Install the equipment at the location in the bridge so that its display can be easily seen.
(2) Select a safe location where the equipment is not exposed to humidity, water splash, rain and
direct sunshine.
(3) Keep enough space for maintenance. Especially, secure enough space at the rear panel where
many cables are concentrated.
(4) Keep the equipment as far away from the wireless transmitter/receiver as possible.
To Next Page
