CVS-126 Chapter 6 Table Attached
0093132702-08 6-3
Bottom alarm (OFF, ON)
Upper depth (0 to 800 m: 5 m)
Lower depth (1 to 800 m: 50 m)
Fish alarm (OFF, ON)
Position (0 to 800 m: 5 m)
Alarm 1
Range (1 to 800 m: 50 m)
Level (Weak, Medium, Strong)
Water temp alarm (OFF, ON (Inside), ON (Outside))
Upper temp alarm (- 5 to 45.0 °C: 20.0 °C)
Lower temp alarm (- 5 to 45.0 °C: 15.0 °C)
Speed alarm (OFF, ON (Upper), ON (Lower))
Speed limit (0 to 80 kn: 0 kn)
Alarm 2
Arrival alarm (OFF, ON)
XTE alarm (OFF, ON)
NAV alarm range (5 to 999 m: 10 m)
NAV start (No.1 to No.10)
NAV cancel (Yes, No)
WPT edit (No.1 to No.10)
WPT delete (No.1 to No.10)
Background color (OFF, White, Black)
NA
V
NAV 1 (Normal (H), Zoom (H), Dual freq, Zoom (L), Normal (L))
NAV 2 (Normal (H), Zoom (H), Dual freq, Zoom (L), Normal (L))
A
Image swap (A|B, B|A)
Image recall (No.1 to No.10)
Image comment (No.1 to No.10)
Image delete (No.1 to No.10)
EVENT key set (Store pos, Store image, Fishing hot spot)
FUNC key set (Image speed, IR, Color rejection, Noise rejection, Shift, Zoom range,
Zoom start, A scope, White line, Background color, Disp width,
NAV start, NAV 1, NAV 2, Image swap, Image recall, Sona-ton)
Operation guide (OFF, ON)
System
B
Sona-tone (OFF, ON)
Image partition ( , )
Fish image (A|B, A| , |B)
