ＡＣＴ－Ｎ０２Ｅ－１
5
Nucom-
MODEL
ITEM
10NL 10NL-100 10NL-150 10NL-200
RATED POWER
AC110·115·120V
±
10% (50/60 Hz)
AC220·230·240V
±
10% (50/60 Hz)
INPUT SIGNAL
4~20mA DC (Standard Specification)
4~12/12~20mA DC (Optional Specification)
OUTPUT TORQUE
490N·m
(50kgf·m)
980N·m
(100kgf·m)
1470N·m
(150kgf·m)
1960N·m
(200kgf·m)
15sec 30sec 45sec 60sec
OPERATION SPEED
12.5sec 25sec 37.5sec 50sec
TRAVEL ANGLE 0~90º
RESOLUTION More than 1/250
DEAD ZONE Max. 0.5% F.S.
LINEARITY Max. 0.5% F.S.
ACTION MODE Direct or reverse action selectable
MODE WHEN SIGNAL “OFF” CLOSE/STOP/OPEN : selectable
PROTECTION
OPEN/CLOSE limit switches
OPEN/CLOSE mechanical stopper
Motor thermal protector (120ºC)
AMBIENT TEMPERATURE Ambient temperature within: -25~55ºC
AC100V 2.4A 2.9A 3.4A
RATED CURRENT
AC110V 2.6A 3.0A 3.5A
AC115V
2.2A
2.6A
3.2A
AC120V
2.4A
2.8A
3.4A
AC200V
1.2A
1.5A
1.8A
AC220V
1.4A
1.6A
1.9A
AC230V
1.1A
1.3A
1.6A
AC240V
1.2A
1.4A
1.7A
MOTOR 100W Reversible
INSULATION GRADE E Class
RATED OPERATION TIME Continuous
POSITION DETECTOR Potentiometer (Backlash revision type)
OUTPUT SIGNAL
4~20mA·DC (Standard spec.)
OPEN / CLOSE limit no-voltage output(Optional extra)
INSULATION RESISTANCE Between power terminal – case : 500V·DC / 100MΩ
WITHSTAND VOLTAGE Between power terminal – case : 1500V·AC / 1 minute
SERVO CONTROL UNITS Resin molded semi-conductors
MANUAL OPERATION Detachable crank handle (Standard accessory)
WIRE INLET G1/2×2 (Water-sealed conduit)
ENCLOSURE PROTECTION NEMA-4X (IP-66)
EXPLOSION PROOF Non explosion-proof
MOUNTING ANGLE 360º all directions
BODY MATERIAL Diecast aluminum
COATING Munsel N-6
WEIGHT 20.5kg 21.5kg 22.5kg
