ＡＣＴ－Ｎ０２Ｅ－１
4
3. FUNCTIONAL SPECIFICATION
Nucom-10NS Nucom-10NM
MODEL
ITEM
STD SPECIAL STD SPECIAL
RATED POWER
AC100·110·115·120V
±
10% (50/60 Hz)
AC200·220·230·240V
±
10% (50/60 Hz)
INPUT SIGNAL
4~20mA·DC (Standard Specification)
4~12/12~20mA·DC (Optional Specification)
OUTPUT TORQUE
49N·m
(5kgf·m)
98 N·m
(10 kgf·m)
196N·m
(20kgf·m)
392 N·m
(40 kgf·m)
15sec(50HZ) 30sec(50HZ) 15sec(50HZ) 30sec(50HZ)
OPERATION SPEED
12.5sec(60HZ) 25sec(60HZ) 12.5sec(60HZ) 25sec(60HZ)
TRAVEL ANGLE 0~90º
RESOLUTION Over 1/250
DEAD ZONE Max. 0.5% F.S.
LINEARITY Max. 0.5% F.S.
ACTION MODE Direct or reverse action selectable
MODE WHEN SIGNAL “OFF” CLOSE/STOP/OPEN : selectable
PROTECTION
OPEN/CLOSE limit switches
OPEN/CLOSE mechanical stopper
Motor thermal protector (120ºC)
AMBIENT TEMPERATURE Ambient temperature within: -25~55ºC
AC100V 0.65A 1.8A
AC110V 0.70A 2.0A
AC115V 0.60A 1.6A
AC120V 0.65A 1.8A
AC200V 0.35A 0.9A
AC220V 0.40A 1.0A
AC230V 0.30A 0.7A
RATED CURRENT
AC240V 0.35A 0.9A
MOTOR 20W Reversible 90W Reversible
INSULATION GRADE E Class
RATED OPERATION TIME Continuous
POSITION DETECTOR Potentiometer (Backlash revision type)
OUTPUT SIGNAL
4~20mA·DC (Standard spec.)
OPEN / CLOSE limit no-voltage output(Optional extra)
INSULATION RESISTANCE Between power terminal – case : 500V·DC / 100MΩ
WITHSTAND VOLTAGE Between power terminal – case : 1500V·AC / 1 minute
SERVO CONTROL UNITS Resin molded semi-conductors
MANUAL OPERATION Detachable crank handle (Standard accessory)
WIRE INLET G1/2×2 (Water-sealed conduit)
ENCLOSURE PROTECTION NEMA-4X (IP-66)
EXPLOSION PROOF Non explosion-proof
MOUNTING ANGLE 360º all directions
BODY MATERIAL Diecast aluminum
COATING Munsel N-6
WEIGHT 4.4kg 8.2kg
