4 — PROGRAMMABLE PARAMETERS

Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022 Return to TOC

pg. 48

INDUCTION MOTOR (ACIM), cont’d PMAC (PERMANENT MAGNET MOTOR), cont’d

— QUADRATURE ENCODER ...................................... p. 137

— 5V Output Enable

— 12V Output Enable

— Encoder Steps

— Phasing Order

— Pullup Override

— ENCODER FAULT SETUP .............................. p. 138

— Fault Detection Enable

— Encoder Pulse Fault Detect Time

— Fault Stall Time

— SPEED FILTERS ................................................... p. 138

— Speed lter Frequency

— TEMPERATURE SENSOR ...................................... p. 145

— Sensor Enable

~ Temperature

~ Motor Temp Cutback

— Braking Thermal Cutback Enable

— Temperature Hot

— Temperature Max

— Motor Temp LOS Max Speed

— Sensor Type

— Sensor Offset

— SENSOR MAP ................................................. p. 145

— Sensor Resistance 0 - 6

— Temperature 0 - 6

— Offset of Windings Due to Sensor Heating

— MOTOR SETUP STATUS ............................... p. 144

~ Current Regulator Setup

~ Slip Gain Setup

~ Base Speed Setup

~ Automated Test Run

— SIN/COS ENCODER .............................................. p. 144

— Swap Motor Direction

— Enable Multiturn Sensor

— Sin Cos Fault Threshold

— Sin Cos Fault Threshold High

— Sin Cos Fault Time

— Sin Cos Startup Time

— Sin Min

— Sin Max

— Cos Min

— Cos Max

— SPEED FILTERS .................................................... p. 144
