- 49 -
95
96
8
5 2000 0
15 3000/3600 0
30 " 30 %
30 " 50 %
30 " 70 %
5 " 100 %
Running-in table
LoadTime (min) RPM
Important
• In order to check that the setting is correct, without tools,
accelerate the engine a few times with no load and check the
exhaust fumes.
• Delivery of diesel fuel is correctly calibrated when the exhaust
gas is slightly coloured by smoke; change the adjustment if
necessary by turning the adjustment screw (fig.96).
Engine power curves are reported at page 17.
Engine testing
