Repair
Fuel system
**Refer to screws reuse rules. (For more information see: 5.3.2 Screws pre-tightening, reuse,
and marking, page 268.)
3.8.5 Fuel filters removal and installation
Previous tasks
q Disconnect fuel pipes and sensors.
q Close fuel supply.
Specific safety instructions
Not applicable.
Special tools
Not applicable.
Consumables and equipment
– Rags
– Cleaner
– Bucket for fuel
Overview
Fig. 139: Task overview
1
Fuel filter 4 Flange joint
2 Flange joint 5 Flange joint
3 Flange joint 6 Screw (M10)
130
© 2022 by Kohler Co. All rights reserved.
KD62V12 33525088601_8_1 EN_US
2022-09
