Repair
Cooling system
Fig. 220: Installing venting lines
u Install venting lines 23 with flange joints 2.
Specific values
Not applicable.
Tightening specifications
Refer to standard tightening torques. (For more information see: 5.3 Standard tightening
torques, page 268.)
3.12.2 Turbocharger cooling lines removal and installation
Previous tasks
q Remove venting lines. (For more information see: 3.12.1 Venting line removal and installation,
page 200.)
Specific safety instructions
NOTICE
Risk of property damage by reuse of sealing.
Leakage by faulty seal.
u Replace all sealings.
Special tools
Not applicable.
206
© 2022 by Kohler Co. All rights reserved.
KD62V12 33525088601_8_1 EN_US
2022-09
