Safety
Accessible areas
2.8.4 Signage recommendations
Information
The machinery owner is responsible for marking the hazardous areas and the fail-safe devices.
The signs must withstand the ambient conditions, and be kept visible and legible during the
entire life cycle.
Additional signs and measures according to project standards and local regulations and stand‐
ards are possible. For example: the signs for the United States market shall comply with ANSI
Z535.4.
The following warning signs must be clearly visible and mounted in the accessible areas:
Sign
(ISO 7010)
Description
ISO 7010/W012 – Warning sign - Electricity
Death or serious injury due to electrical shocks!
ISO 7010/W017 – Warning sign - Hot surface
Severe injuries due to hot surfaces!
ISO 7010/W025 – Warning sign - Counterrotating rollers
Severe injuries due to drawing-in movement!
ISO 7010/M002 – Mandatory action sign - Refer to instruction manual/booklet
In order to ensure that all residual risks are known by the personnel, the
system documentation must be read and understood. Make sure that all
residual risks according to the risk assessment are reflected in the system
documentation. Provide documentation to the personnel according to the
“Target audience”.
Tab. 8: Engine area signs requirement
48
© 2022 by Kohler Co. All rights reserved.
KD62V12 33525088601_8_1 EN_US
2022-09
