Repair
Exhaust gas system
Removal
u Loosen V-clamp 11.
u Remove screws 3 from outlet manifolds 2.
u Remove outlet manifolds 2.
u Remove screws 3 from outlet manifolds 9.
u Remove outlet manifolds 9.
u Remove screws 3 from outlet manifolds 10.
u Remove outlet manifolds 10.
u Remove screws 3 from outlet manifolds 13.
u Remove outlet manifolds 13.
Installation
u Install plug 6 with sealing ring 5 in outlet manifolds 2, 10.
u Install plug 8 with sealing ring 7 in outlet manifolds 2.
Information
At first, install the whole line without tightening the screws.
Tighten all screws to torque at the end of installation, making sure that compensators are
aligned evenly.
u Apply hot temperature grease to lips of V-clamps 11.
u Mount outlet manifolds 2, 10 together with seals 4, V-clamps 11 and compensator 12.
u Place outlet manifolds 2, 10 with seals 1 and screws 3.
u Mount outlet manifolds 9 on outlet manifolds 2, 10 with seals 4, V-clamps 11 and compen‐
sator 12.
u Place outlet manifolds 9 with seals 1 and screws 3.
u Mount outlet manifolds 2, 13 on outlet manifolds 9 with seals 4, V-clamps 11, and compen‐
sator 12.
u Mount outlet manifolds 2, 13 together with seals 4, V-clamps 11, and compensator 12.
u Place outlet manifolds 2, 13 with seals 1 and screws 3.
u
Tighten plugs 6, 8, V-clamps 11, and screws 3 to torque.
Specific values
Not applicable.
KD62V12 33525088601_8_1 EN_US
2022-09
© 2022 by Kohler Co. All rights reserved.
185
