Kohler KD62V12 User Manual

Repair
Exhaust gas system
Reference
Key Screw specifications
Lubricant *
Reuse**
Torque Angle (°)
Step
± 5%
Step
± 5°
2 52 Nm
38 ft-lb
- -
2 410AD DIN 908 G3/8 A MH Yes 1 60 Nm
44 ft-lb
- -
3 410AE DIN 908 M16x1.5 MH Yes 1 50 Nm
37 ft-lb
- -
4 410AF M8x1.25 MH Yes 1 20 Nm
15 ft-lb
- -
Tab. 38: Tightening specifications table
*Lubricants:
MG = Molykote G-n-plus
MW = Castrol Optimol paste white T
MH = Molykote HSC
O = Engine oil
XX = Loctite 243
YY = Loctite 577
**Refer to screws reuse rules. (For more information see: 5.3.2 Screws pre-tightening, reuse,
and marking, page 268.)
KD62V12 33525088601_8_1 EN_US
2022-09
© 2022 by Kohler Co. All rights reserved.
187
