Product description
Technical description
Fig. 10: Hardware nameplate
1 Product designation 5 Serial number
2 Engine control unit ID number 6 Supplier number
3 Hardware version 7 QR Code
4 Delivery date
Information
u The information on the engine control unit nameplate corresponds to the delivery status (ex:
works Kohler Co.). Depending on software updates in the field, it may be the case that this
information is no longer up to date.
u The real information can be viewed in the device display or read out with the KOHLER diag‐
nosis and service tool KODIA.
Crankcase identification
The crankcase identification is stamped onto the left side of the crankcase.
Fig. 11: Crankcase identification location
Connecting rod identification
The connecting rod identification is stamped on the connecting rod and on the connected rod
bearing cap.
KD62V12 33525088601_8_1 EN_US
2022-09
© 2022 by Kohler Co. All rights reserved.
23
