Repair
Cylinder head
Fig. 89: Mounting lifting lug
u Lubricate bolts 9 with Castrol Optimol paste white T.
u Mount lifting lug 10 with extended length bolts 9.
u Insert and tighten the bolts 6 by hand.
u Tighten all bolts 6 with the torque wrench according to the specifications. (For more infor‐
mation see: Tightening specifications, page 95.)
Information
If cylinder heads 1 are connected with a lifting lug bracket, both cylinder heads 1 need to be
removed.
Information
Bleed coolant circuit at the end of installation.
Specific values
Not applicable.
94
© 2022 by Kohler Co. All rights reserved.
KD62V12 33525088601_8_1 EN_US
2022-09
