Service and Repair Manual Repair
Fuel system
u Place guiding rods.
Fig. 157: Installing fuel pump lifting device
u Use lifting device to position fuel pumps into gearbox.
u Place screw 3.
u Remove guiding rods.
u Place remaining screws and remove lifting tools.
u Tighten screws to torque following the given order. (For more information see: Tightening speci-
fications, page 138.)
u Install HP pump piping.
u Perform the venting on the fuel circuit.
Specific values
Not applicable.
KD83V16 33525088901_2_1 EN_US
2021-07
© 2021 by Kohler Co. All rights reserved.
137
