Fuel system
u Remove remaining screws 3.
Fig. 155: Installing fuel pump lifting device
u Install fuel pump lifting device.
u Remove fuel pumps.
u Remove guiding rods.
Installation
u Install new O-ring.
Information
Lubricate HP connection o-ring with Castrol Optimol paste white T.
Lubricate shaft teeth and o-rings with engine oil.
Fig. 156: Fuel pump O-rings
136
© 2021 by Kohler Co. All rights reserved.
KD83V16 33525088901_2_1 EN_US
2021-07
