Service and Repair Manual Repair
Charge air system
Specific safety instructions
NOTICE
Risk of property damage by reuse of sealing.
Leakage by faulty seal.
u Replace all sealings.
Special tools
Not applicable.
Consumables and equipment
– Rags
– Cleaner
– Grease (Optimol)
Overview
Fig. 169: Task overview
1 Nut (M10) 9 Locking plate
2 Seal 10 Screw (M10)
3 Screw (M10) 11 Screw (M10)
4 Nut (M10) 12 Screw (M10)
5 Compensator 13 Compensator
6 Pipe 14 Screw (M10)
7 Clamp 15 Distance sleeve
See next page for continuation of the image legend
KD83V16 33525088901_2_1 EN_US
2021-07
© 2021 by Kohler Co. All rights reserved.
149
