Service and Repair Manual Repair
Cooling system
Fig. 231: Installing cover
u Insert o-ring 8.
u Insert cover 4.
u Tighten screws 9.
Specific values
Not applicable.
Tightening specifications
Refer to standard tightening torques. (For more information see: 5.3 Standard tightening torques,
page 274.)
3.10.2 Venting line removal and installation
Previous tasks
Not applicable.
Specific safety instructions
NOTICE
Risk of property damage by reuse of sealing.
Leakage by faulty seal.
u Replace all sealings.
Special tools
Not applicable.
Consumables and equipment
– Rags
– Cleaner
– Loctite 243
KD83V16 33525088901_2_1 EN_US
2021-07
© 2021 by Kohler Co. All rights reserved.
205
