Service and Repair Manual Repair
Cooling system
Specific safety instructions
NOTICE
Risk of property damage by reuse of sealing.
Leakage by faulty seal.
u Replace all sealings.
Special tools
Not applicable.
Consumables and equipment
– Vaseline
– Rags
– Cleaner
Overview
Fig. 248: Task overview
1 Screw (M10) 14 Adaptor
2 Plate 15 Pipe
3 Clamp 16 Screw (M10)
4 T connector 17 O-ring
5 Screw (M8) 18 O-ring
6 Pipe 19 Aggregate support connector
7 Pipe 20 Screw (M10)
8 Distance sleeve 21 Pipe
9 Screw (M8) 22 Retaining plate
10 Screw (M8) 23 Pipe
11 Clamp 24 Fitting
12 Screw (M8) 25 Pipe
13 Retaining plate 26 Pipe
KD83V16 33525088901_2_1 EN_US
2021-07
© 2021 by Kohler Co. All rights reserved.
219
