Cooling system
Tightening specifications
Fig. 247: Clamp screws
Reference
Key Screw specifications
Lubricant *
Reuse**
Torque Angle (°)
Step
± 5%
Step
± 5°
1 383AA ISO 4014 M10x1.5x60-8.8-FLZN - Yes 1 30 Nm
22 ft-lb
- -
Tab. 45: Tightening specifications table
*Lubricants:
MG = Molykote G-n-plus
MW = Castrol Optimol paste white T
MH = Molykote HSC
O = Engine oil
XX = Loctite 243
YY = Loctite 577
**Refer to screws reuse rules. (For more information see: 5.3.2 Screws pre-tightening, reuse and
marking, page 274.)
Turbocharger cooling lines removal and installation (EATS config-
uration)
Previous tasks
q Remove venting lines. (For more information see: 3.10.2 Venting line removal and installation,
page 205.)
