Kohler KD83V16 Service And Repair Manual

Repair Service and Repair Manual
Electrical system
Specific values
Belt tension: 165 Hz (Min 149 Hz - Max 182 Hz).
Tightening specifications
Fig. 284: Belt tensioner
Reference
Key Screw specifications
Lubricant *
Reuse**
Torque Angle (°)
Step
± 5%
Step
± 5°
1 441AD M10x55-10.9-Zinc Coating - Yes 1 50 Nm
37 ft-lb
- -
Tab. 54: Tightening specifications table
*Lubricants:
MG = Molykote G-n-plus
MW = Castrol Optimol paste white T
MH = Molykote HSC
O = Engine oil
XX = Loctite 243
YY = Loctite 577
**Refer to screws reuse rules. (For more information see: 5.3.2 Screws pre-tightening, reuse and
marking, page 274.)
3.11.2
Starter removal and installation (SL 260)
Previous tasks
Not applicable.
248
© 2021 by Kohler Co. All rights reserved.
KD83V16 33525088901_2_1 EN_US
2021-07
