Maintenance Operation and Maintenance Manual
Lubricating system
Ensure that:
q Preparatory maintenance activities are fullfilled. (For more information see: 5.5 Preparatory
maintenance activities, page 90)
q Original KOHLER oil filters with the seals are provided.
q A suitable drainage container is available.
q The required quantity of approved oil is provided. (For more information see: 5.11 Lubricants
and operating fluids, page 120)
The oil centrifuge is equipped with a stop valve which stops the oil inlet.
The oil centrifuge is attached to the engine on the right side.
Replacing centrifuge paper filter
Fig. 61: Oil centrifuge
1 Centrifuge base 5 Rotor cylinder
2 V-clamp 6 Paper filter
3 Rotor 7 Rotor base
4 Cover 8 Rotor cover
104
© 2018 by Kohler Co. All rights reserved.
KD83V16 33521030601_0_1 EN_US
2018-07
