Operation and Maintenance Manual Maintenance
Lubricating system
2 Oil drain aggregate support. Engine left
side
Fig. 70: Oil drain - engine left side
1 Oil drain on oil cooler
On each drain-off point:
u Unscrew and remove plug or open valve.
u Let the oil flow into the container.
u Wait until no more oil drips.
u Clean the drain-hole, plug or valve and the surrounding area with a clean rag.
u Check washer condition.
Troubleshooting
If washer is worn or broken:
u Replace washer.
u Refit the plug or close the valve.
u Tighten plug according standard torque.
Filling Diesel engine oil
q Engine oil drained.
q Filters replaced.
q Draining plugs and valves closed.
KD83V16 33521030601_0_1 EN_US
2018-07
© 2018 by Kohler Co. All rights reserved.
109
