Kold-Draft SC200 Series - Page 23

SC200 Installation& Operation Manual 3-16
21
102148301
SC200 FAN ASSY .KIT
Qty per
Uom
Description
6.0000
PC
SCREW-#8-18 X 1/2 PH PAN SS
4.0000
PC
LOCKNUT-8-32 SS W/NYLON INSERT
1.0000
EA
SC FAN MOTOR - 115V & 230V 1550 RPM CCW & CW
1.0000
EA
SC FAN BLADE - PLASTIC 200 MM DIA. 28 DEGREE
PITCH
1.0000
EA
SC FAN BLADE WALL RING - PLASTIC 200 MM DIA.
BLADE
3.0000
EA
22-18 AWG INSULATED BUTT SPLICE CONNECTOR
30.0000
IN
FOAM TAPE .25" x .50" x 100' WITH PSA-1 ADHESIVE
