Koldfront CAC10000W User Manual

7
5. Cut the side channel sealing strip into two equal lengths. Remove the protective backing
and apply it to the back of the side channel starting just below the window panel frame.
Remove any excess length so that the seal is even with the bottom of the side channel.
Remove the Front Panel
1. Remove the two (2) front retaining screws from the front frame.
2. Gently pull the front out and lift up to release it from the case.
3. Release the control board plug.
A. Side channel
sealing strip
B. Side channel
C. Window panel
frame
NOTE: Be careful not to push or pull the louvers when removing the front panel.

Koldfront CAC10000W Specifications

General

Brand	Koldfront
Model	CAC10000W
Category	Air Conditioner
Language	English
