9
4. Place the sliding window sash sealing strip between the far vertical edge of the inner window
and the glass of the outer window.
5. Install the window locking bracket to lock the inner window to the base of the outer window.
• Use one #8x3/4” screw or #8-32x3/4” self-threading screw to fasten the window locking
bracket in place.
6. Replace the front panel by reversing the steps in the “Remove the Front Panel” section. Make
sure the exhaust control level passes through the front in the proper location.
Installing Air Conditioner into a Casement Window
Follow the steps listed below to install the air conditioner into the window:
1. Using two (2) or more persons, safely lift the air conditioner into the windowsill on top of the
previously installed window platform:
• The air conditioner should sit so that the window panel frame and side channels are
against the top and side window jambs. The side channels should overlap the side
window jambs equally.
