Koldfront WTC8002WCO - Preparations for Installation

3
Preparations for Installation
Before you begin, make sure you have all the parts and tools necessary for installation.
Parts Supplied:
Tools You May Need:
• Flat Screwdriver or Putty Knife • Phillips Screwdriver • Tape Measure • Level • Drill
Note: You may need to contact an electrician if your room’s circuit is not able to power your unit.
Parts Supplied
The parts below are intended to be used in conjunction with a Koldfront branded Wall
Sleeve.
Part Name
Size
Qty Included
Horizontal Insulation Seals
1” x
3
/
8
” x 25”
1
Vertical Insulation Seals
1” x
3
/
8
” x 14”
2
Horizontal Insulation Seals
1” x
3
/
4
” x 14”
2
Foam Support Blocks
1” x 1
1
/
2
” x 14”
2
Tapered Support Blocks
1” x 1” x 17” (tapered to ¾”)
2
Main Insulating Seal (stuffer seal)
1” x 1
1
/
2
” x 84”
1
Trim Frame (sides)
2
Trim Frame (top / bottom)
2
Ground Wire (green)
1
Toothed washers for grounding screw
2
Grounding Screw
1
Rear Louver Panel / Grille (aluminum)
1
Nuts (plastic)
4
Washers (for screws)
4
Screws
4
Additional and/or duplicate parts noted below have been included to allow for installation
into non-Koldfront branded Wall Sleeves or to accommodate non-standard installation
scenarios. Any unused parts may be discarded at your discretion.
Part Name
Size
Qty Included
Centering / Support Blocks
4
1
/
2
” x 3
1
/
2
” x1
1
/
2
”
4
Plastic Divider
1
/
8
” x 4
1
/
2
” x 14
1
/
2
” x
2
Horizontal Insulation Seals
1” x
3
/
8
” x 25”
2
Horizontal Insulation Seals
1” x 1
1
/
2
” x 25”
3
Note: To avoid risk of injury and/or product/property damage, please take the following
precautions:
 Two or more people are needed to properly handle and install.
 Use proper lifting and carrying techniques.
 Before installation, make sure to inspect the window and sill to ensure they are able to handle
the weight and size of this unit.
 Wearing protective gloves will help to avoid injury from sharp edges.
