Kolver FAB Series User Manual

Vers. 111219 Page 36
SPARE PARTS:
Posizione
Descrizione
Quantità
Codice
1
Upper panel EDU2AE/TOP
1
819003
2
3x5 Button head screw burnished TX10
17
872444
3
Motor board
1
852521/SW
4
M3 toothed washer
5
800041
5
Switching 48V 600W
1
872490
6
M3 burnished nut
11
800056
7
I/O EDU 2AE/TOP/TA board
1
852525/TA
8
M3 brass nut
2
800056/O
9
Ground cable
1
800090/E
10
Ferrite
1
872468
11
Display board EDU2AE/TOP
1
852526
12
Front panel EDU2AE/TOP /TA
1
819002/USB
13
Membrane EDU 2AE/TOP/TA
1
819006
14
USB Flat cable
1
872474
15
USB Device
1
852424
16
USB Pen drive
1
872475
17
M12 8pin + nut + ferrite connector
1
201766/LTA
18
M3 Washer h0,5 mm
4
800042
19
Spacer 15mm dest 4,8 mm
4
890004/T
20
Plastic support
4
800016/B
21
Bottom panel EDU2AE/TOP/SW
1
819001/SW
22
Flat cable 10 vie
1
819007
23
Flat cable 20 vie
1
872438/T
24
Sapcer da 6,3 mm dest 6.2mm
4
241003
25
Fuse 3.15A
2
800619
26
I/O Connector 9 pin spacing 3.81
1
800164
27
I/O Connector 11 pin spacing 3.81
1
800165
28
I/O Connector 14 pin spacing 3.81
1
800166
29
I/O Connector 10 pin spacing 3.81
1
800102
30
Filtered plug
1
800718
31
Main board support
2
872442
Label
1
818006/SW
Schuko Cable
1
800620
